Notes
The genotyping protocol(s) presented here have been optimized for reagents and conditions used by The Jackson Laboratory (JAX).
To genotype animals, JAX recommends researchers validate the assay independently upon receipt of animals into their facility.
Reaction cycling temperature and times may require additional optimization based on the specific genotyping reagents used.
Expected Results
Mutant = 241 bp
Heterozygote = 241 bp and 335 bp
Wild type = 335 bp
>chr5:73636429-73636763 335bp CTCCCTCCAGTGAACAGCAC GATCCGTCTGCCTCTACAGC
JAX Protocol
Protocol Primers
| Primer | 5' Label | Sequence 5' → 3' | 3' Label | Primer Type | Reaction | Note |
|---|---|---|---|---|---|---|
| 18349 | TCA GCA GCC TCT GTT CCA C | Mutant Forward | A | Mut F | ||
| 49834 | CTC CCT CCA GTG AAC AGC AC | Wild type Forward | A | Wt F | ||
| 49835 | GAT CCG TCT GCC TCT ACA GC | Wild type Reverse | A | Wt R | ||
| 49836 | CCA TGA CAG TAT TTT CTT TAG TGC | Mutant Reverse | A | Mut R |
Reaction A
| Component | Final Concentration |
|---|---|
| ddH2O | |
| Kapa 2G HS buffer | 1.30 X |
| MgCl2 | 2.60 mM |
| dNTP KAPA | 0.26 mM |
| 18349 | 0.50 uM |
| 49834 | 0.50 uM |
| 49835 | 0.50 uM |
| 49836 | 0.50 uM |
| Glycerol | 6.50 % |
| Dye | 1.00 X |
| Kapa 2G HS taq polym | 0.03 U/ul |
| DNA |
Cycling
| Step | Temp °C | Time | Note |
|---|---|---|---|
| 1 | 94.0 | -- | |
| 2 | 94.0 | -- | |
| 3 | 65.0 | -- | -0.5 C per cycle decrease |
| 4 | 68.0 | -- | |
| 5 | -- | repeat steps 2-4 for 10 cycles (Touchdown) | |
| 6 | 94.0 | -- | |
| 7 | 60.0 | -- | |
| 8 | 72.0 | -- | |
| 9 | -- | repeat steps 6-8 for 28 cycles | |
| 10 | 72.0 | -- | |
| 11 | 10.0 | -- | hold |
JAX uses a very high speed Taq (~1000 bp/sec), use cycling times recommended for your reagents.
JAX uses a 'touchdown' cycling protocol and therefore has not calculated the optimal annealing temperature for each set of primers.
