Notes
Taqman qPCR protocols are run on a real time PCR instrument. Use an appropriate instrument specific Fluorophore/Quencher combination. The transgene genotype is determined by comparing ΔCt values of each unknown sample against known homozygous and hemizygous controls, using appropriate endogenous references.
The genotyping protocol(s) presented here have been optimized for reagents and conditions used by The Jackson Laboratory (JAX).
To genotype animals, JAX recommends researchers validate the assay independently upon receipt of animals into their facility.
Reaction cycling temperature and times may require additional optimization based on the specific genotyping reagents used.
Expected Results
Mutant= 114 bp
Wild Type = 145 bp
>chr8:26160596+26160740 145bp TGCACTGTCAAGTGTCTTCG AAGATAAAGAAAAGCCCCACAC
Sequence
Wt Sequence:
Mutant Sequence:
JAX Protocol
Protocol Primers
| Primer | 5' Label | Sequence 5' → 3' | 3' Label | Primer Type | Reaction | Note |
|---|---|---|---|---|---|---|
| 35946 | AAG ATA AAG AAA AGC CCC ACA C | Wild type Reverse | A | |||
| 35948 | Fluorophore-1 | AGA GTC TCC TTA GGA TGG GGT AA | Quencher-1 | WT Probe | ||
| 36603 | TGC ACT GTC AAG TGT CTT CG | Common | A | |||
| 36604 | AAC CAC TAA GCC CCA ACA GT | Mutant Reverse | A | |||
| 36605 | Fluorophore-2 | AGC TTC CTG AGA AAG GAT AAC AAA A | Quencher-2 | MUT Probe |
Reaction A
| Component | Final Concentration |
|---|---|
| Kapa Probe Fast QPCR | 1.00 X |
| ddH2O | |
| 35946 | 0.40 uM |
| 36603 | 0.40 uM |
| 36604 | 0.40 uM |
| Wt Probe | 0.15 uM |
| Mutant Probe | 0.15 uM |
| DNA |
Cycling
| Step | Temp °C | Time | Note |
|---|---|---|---|
| 1 | 95.0 | -- | |
| 2 | 95.0 | -- | |
| 3 | 60.0 | -- | |
| 4 | -- | repeat steps 2-3 for 40 cycles | |
| 5 | 40.0 | -- | Forever |
JAX uses a very high speed Taq (~1000 bp/sec), use cycling times recommended for your reagents.
Strains Using This Protocol
This is the only strain that uses this protocol.
