Notes
Taqman qPCR protocols are run on a real time PCR instrument. Use an appropriate instrument specific Fluorophore/Quencher combination.
The genotyping protocol(s) presented here have been optimized for reagents and conditions used by The Jackson Laboratory (JAX).
To genotype animals, JAX recommends researchers validate the assay independently upon receipt of animals into their facility.
Reaction cycling temperature and times may require additional optimization based on the specific genotyping reagents used.
Expected Results
Mutant= 80 bp
Wild Type = 86 bp
>chr14:54545657-54545742 86bp CCATGACCCCAGTTCAGGT CACATCGAACTGAAAAAGCTG
Sequence
CCAAATGTTAGGATTAGTGTACCACCATTCCTGGCTCTCGTGATGCCAGTTGTTTGGTTATGAGGCTCTCTGTGTTCTCACACCACTGGCAGGTCTCCCTCGTGctaacagtctgtgtgcctctaggatttcgtgtggatgaaagcccggctccagctggaggtggaggagcagctcaagaggaaatgcttcacgctgctgtgctaccatgaccccagttcaggtgtgagcctccccggccTGCTCATGTGCCCTCAGTTCCTGGGCTAGCCAGCTTTTTCAGTTCGATGTGGGTGTGAGACAGGGTACTCTGTATTCCAGGGTGTCTAGCCAGGAACTCACTATGTTACCCAAGTTGGTCTCAAACCTGTGGCAAGCCTGCCTGGGTGCTCCAAGTGTTGAGATTATTGGCATGACCCACCATGCCAACTTTAGACTACTCTGAGACTTTAGAATCAGAAATGATGGTTTATTTCCTCAGGAGTGGGTTT
Mutation details
JAX Protocol
Protocol Primers
| Primer | 5' Label | Sequence 5' → 3' | 3' Label | Primer Type | Reaction | Note |
|---|---|---|---|---|---|---|
| 44194 | CCA TGA CCC CAG TTC AGG T | Wild type Forward | A | |||
| 44195 | CAC ATC GAA CTG AAA AAG CTG | Common | A | |||
| 44196 | TCT CAC ACC ACT GGC AGG T | Mutant Forward | A | |||
| 44197 | Fluorophore-1 | CCC GGC CTG CTC ATG TG | Quencher-1 | WT Probe | ||
| 44198 | Fluorophore-2 | CCC TCG TGT GCT CAT GTG C | Quencher-2 | MUT Probe |
Reaction A
| Component | Final Concentration |
|---|---|
| Kapa Probe Fast QPCR | 1.00 X |
| ddH2O | |
| 44194 | 0.40 uM |
| 44195 | 0.40 uM |
| 44196 | 0.40 uM |
| Wt Probe | 0.15 uM |
| Mutant Probe | 0.15 uM |
| DNA |
Cycling
| Step | Temp °C | Time | Note |
|---|---|---|---|
| 1 | 95.0 | -- | |
| 2 | 95.0 | -- | |
| 3 | 60.0 | -- | |
| 4 | -- | repeat steps 2-3 for 40 cycles | |
| 5 | 40.0 | -- | Forever |
JAX uses a very high speed Taq (~1000 bp/sec), use cycling times recommended for your reagents.
Strains Using This Protocol
This is the only strain that uses this protocol.
